ES Protezione delle macchine
Sistemi di recinzione di sicurezza per robot
Robot Safety Fencing Systems for automation lines that need a hard access boundary, fast integration, and a clean retrofit path without on-site welding.
Core specifications that matter in a live cell
| Item | Valore |
|---|---|
| Materiale principale | Acciaio al carbonio Q235 |
| Common post sizes | 50×50 mm, 40×60 mm, 60×60 mm |
| Common project height | 2000 mm |
| Maglia di apertura | 20×100 mm |
| Wire diameter | 4.0 mm |
| Gate and lock logic | Metal handle lock, support caster, hinge gate support parts, and lock carrier for electronic safety lock use |
| Safety interlock reference | Omron D4NL-4EFG-B with D4DS-K3 key |
Why integrators choose this layout
01. Built for safety hardware, not field improvisation
The fence is prepared for interlock-ready layouts from the start, so integrators do not need to spend site time drilling, shimming, or building one-off brackets for every project.
02. Modular steel structure that fits real automation footprints
Robot cells, palletizers, conveyors, and ASRS zones rarely match a generic fence module. This system is built to cover controlled access spaces while keeping the boundary tight and practical.
03. Retrofit-friendly assembly with no on-site welding
Field welding adds shutdown risk, hot-work control, and finish problems. A modular steel fence gives engineering teams a cleaner installation path and a more stable handover.
Where the system fits best
- Robot cells with strict access control around moving equipment
- Packaging lines and palletizing lines that need interlocked gate entry
- Conveyor and material-handling zones where space is limited but safety distance still matters
- Warehouse automation and ASRS areas that require a modular perimeter
What to check before release
Confirm post height, mesh opening, gate direction, lock carrier position, and the interlock model before the layout is frozen. That is where Robot Safety Fencing Systems saves time: the structure already anticipates common integration points instead of forcing the team to invent them on site.
Need a perimeter that the controls team can trust?
Robot Safety Fencing Systems give your project a standard boundary, a stable safety interface, and a faster route from layout approval to installation.
